Automatic H Beam Production Line , H Beam Assembling Welding Straightening Machine

    Buy cheap Automatic H Beam Production Line , H Beam Assembling Welding Straightening Machine from wholesalers

    Buy cheap Automatic H Beam Production Line , H Beam Assembling Welding Straightening Machine from wholesalers
    • Buy cheap Automatic H Beam Production Line , H Beam Assembling Welding Straightening Machine from wholesalers
    • Buy cheap Automatic H Beam Production Line , H Beam Assembling Welding Straightening Machine from wholesalers
    • Buy cheap Automatic H Beam Production Line , H Beam Assembling Welding Straightening Machine from wholesalers
    • Buy cheap Automatic H Beam Production Line , H Beam Assembling Welding Straightening Machine from wholesalers

    Automatic H Beam Production Line , H Beam Assembling Welding Straightening Machine

    Ask Lasest Price
    Delivery Time : 30 working days after down payment
    Brand Name : FRIENDSHIP MACHINERY
    Model Number : PHJ
    Certification : CE, ISO
    • Product Details
    • Company Profile

    Automatic H Beam Production Line , H Beam Assembling Welding Straightening Machine


    Automatic H Beam Production Line


    H Beam Assembling Welding Straightening Machine


    H beam 3 in 1 machine


    H beam combination machine


    Double H-beam assembling, welding and straightening machine production line is composed by 2 sets of H-beam assembling, welding and straightening machines, driving roller conveyor, idler roller conveyor, driving elevating roller conveyor, flange centering device, 90° overturning machine, overturning machine with magnetic sucker, conveying chain moving device.

    2 sets of H-beam assembling, welding and straightening machines are laid in parallel staggered. The first machine will assemble one flange plate and one web plate to T beam, second machine will add another flange plate to this T beam, then assembled to H-beam.

    • Web height: 200-1500mm
    • Web thickness: 6-14mm
    • Flange width: 150-800mm
    • Flange thickness: 6-20mm
    • Workpiece length: 4000-12000mm
    • Assembling and welding speed: 0.3-3m/min
    • Main machine power: 4 kW×2 = 8 kW
    • Roller conveyor power: 0.55×14 = 7.7 kW
    • Conveying chain moving motor power: 3 kW
    • Flux recycling power: 3 kW×4 = 12 kW
    • Hydraulic station power: 5.5 kW×4 = 11 kW
    • Overturning hydraulic station power: 5.5 kW×2 = 11 kW
