    Automated H Beam Assembling Machine For Steel Construction Need

    Ask Lasest Price
    Brand Name : Friendship Machinery
    Model Number : HG-2000
    Certification : CE, ISO
    Price : USD23,000
    Supply Ability : 20 sets per month
    Delivery Time : 30 working days after down payment
    • Product Details
    • Company Profile

    Automated H Beam Assembling Machine For Steel Construction Need


    Automated H Beam Assembling Machine For Steel Construction Need


    1. Major technical parameters


    ● Height of the web: 200-1500mm

    ● Thickness of the web: 6-32mm

    ● Width of the flange: 200-800mm

    ● Thickness of the flange: 6-40mm

    ● Length of the work piece: 4000-16000mm

    ● Length of the conveyor (input and output): 28000mm

    ● Assembling speed: 500-1200mm/min

    ● Electrical system: Siemens

    ● KR-350 gas shielded welding source


    2. Performance


    HG-1500 H assembling machine is a specially designed for the molding of H beam. During the assembling of the H beam, hydraulic clamp is used for synchronized camping and automatic centering to guarantee the accurate positioning of web of different widths during the specified range. We have assistant clamp on our frame.



    3. Provide goods bound and compose parts


    ● Machine body: main frame, up pinch gantry device, clamping aligning unit, driving reducer
    ● Input conveyor: 14000mm
    ● Out conveyor: 14000mm
    ● Hydraulic system: oil pump station high pressure hose hydraulic cylinders etc
    ● Auto-tack welder system: 2 sets of KR-350 gas shielded welder sources and welding guns
    ● Spare parts: buttons*3, 3 pieces of 4A, 2A fuses



    4. Technique document (send out to clientele after bargain go into effect)


    ● Operating manual (including electrical diagram)
    ● Delivery list
    ● Certificate
    ● Foundation diagram
    ● Transducer operation instruction, hydraulic pump operation instruction



    Quality Automated H Beam Assembling Machine For Steel Construction Need for sale
