    Gantry CNC Plasma Cutting Machine , Plasma Cutting Machines

    Ask Lasest Price
    Brand Name : Friendship Machinery
    Model Number : GSD
    Certification : CE, ISO
    Payment Terms : L/C, T/T
    Supply Ability : 20 sets per month
    Delivery Time : 25 working days
    • Product Details
    • Company Profile

    Gantry CNC Plasma Cutting Machine , Plasma Cutting Machines


    1. Performance index

    - Cutting shape: It can cut Arbitrary steel part of planar shape constructed by programmable cutting straight line and circular arc

    - CNC system and Mached Torch Height controller: STARTFIRE (China domestic famous brand)

    - Strong Machine Frame to make the macine durable use

    - Drive Mode: adopt step-by-step driving technology(servo motor driving optional)

    - Running gear: adopt zero clearance wheel gear and rack transmission to make sure the running accuracy

    - USB Interface: the machine can read ArtCAM,CAD,FASTCAM,StarCAM profiles etc.


    2. Product Parameter

    ITEMPARAMETER
    ModelGantry type plasma cutting machine
    Cutting methodPlasma and Flame
    Maximum cutting width3000mm
    Maximum cutting length7000mm
    Cutting torch lifting stroke≤100mm
    Cutting speed0-8000 mm/min
    Maximum idle speed15000mm/min
    Running accuracy≤ 0.005mm
